Standard Cables

Standards for automotive cables

DIN EN 13602 : Soft Annealed Electrolytic Cu - ETP1

DIN 72551, ISO 6722-1 : Bare or Tinned Conductor Construction & Insulation

Cable Types
FLRY- A (T1) – thin wall PVC Insulation -40°C to +85°C (3000 hrs)
FLRY- B (T2) – thin wall PVC Insulation -40°C to +105°C (3000 hrs)
FLRY- C (T3) – PVC / TPE / XLPO Insulation -40°C to +125°C (3000 hrs)
FLRY- D (T4) – XLPO / TPEE Insulation -40°C to +150°C (3000 hrs)
FLRY- E (T5) – SILICON Insulation -40°C to +175°C (3000 hrs)
FLRY- F (T6) – Fluoropolymer Insulation (Extruded / Sintered) -40°C to +200°C (3000 hrs)
FLY – PVC Insulation -40°C to +105°C (3000 hrs)
FLYW – PVC Insulation – Hot Pressure Resistant -40°C to +125°C (3000 hrs)
FLYK – PVC Insulation – Cold Resistant & Increased Flexibility -50°C to +105°C (3000 hrs)
FLRYK – thin wall PVC Insulation – Cold Resistant -50°C to +105°C (3000 hrs)
FLRYW- TYPE A – thin wall PVC Insulation – Hot Pressure Resistant -40°C to +125°C (3000 hrs)
FLRYW- TYPE B – thin wall PVC Insulation – Hot Pressure Resistant -40°C to +125°C (3000 hrs)
FLR4Y- TYPE A – Polyamide Insulation -40°C to +105°C (3000 hrs)
FLR4Y- TYPE B – Polyamide Insulation -40°C to +105°C (3000 hrs)
FLRYH – thin wall PVC Insulation – Highly Flexible Fine Wire -40°C to +105°C (3000 hrs)
FL11Y – TPE-U Insulation for Battery Cables -40°C to +110°C (3000 hrs)
FLYY – PVC Insulation & Sheath -40°C to +110°C (3000 hrs)
Abbreviations
FL Automotive Cable Low Voltage
R Reduced Insulation Wall Thickness
S Thin Wall Type
Y PVC Insulation
YW Heat & Hot Pressure Resistant PVC
TYPE A Symmetrical (FLRYW - A & FLR4Y-A)
YK Cold Resistant PVC
YH PVC & Highly Flexible
11Y TPE-U Insulation
4Y TPE-U Insulation
TYPE B Unsymmetrical (FLRYW -B & FLR4Y-B)
